IP68 Plastic/Nylon Cable gland Cable
HS-M16
FOB
2000 packs
1000,000packs / Day
Yueqing,China
10 daysDay
Material: Nylon66,94v-2. Tight ring from rubber
Operating Temperature: - 40°C to 100°C
Color: Black White
Package:100pcs
Brand: WAHSURE
Feature：1 .Special designation,good strengthsile and none damage to electrical maching.
2.not need to dismetgrate the fix terminal,cable can be inserted Through direcity then tighten easy and save time.
Application：Used for machiery cotrol box,distribution plate,machine and electrical. etc.
ITEM: HS-M12,HS-M14,HS-M16,HS-M18,HS-M20,HS-M22,HS-M24,HS-M25,HS-M27,HS-M30,HS-M32,HS-M36,HS-M40,HS-M50,HS-M63
Operating Temperature: - 40°C to 100°C
Color: Black White
Package:100pcs
Brand: WAHSURE
Feature：1 .Special designation,good strengthsile and none damage to electrical maching.
2.not need to dismetgrate the fix terminal,cable can be inserted Through direcity then tighten easy and save time.
Application：Used for machiery cotrol box,distribution plate,machine and electrical. etc.
ITEM: HS-M12,HS-M14,HS-M16,HS-M18,HS-M20,HS-M22,HS-M24,HS-M25,HS-M27,HS-M30,HS-M32,HS-M36,HS-M40,HS-M50,HS-M63
Quantity
Material: Nylon66,94v-2. Tight ring from rubber
Operating Temperature: -40℃-100℃
Color: Black White
Package:100pcs or Special request Packing available
Brand: WAHSURE
Type: Metric Thread Cable Gland, M Type, Nylon Cable Gland, Metric Thread Cable Gland, M Type, Nylon Cable Gland,Tight ring from rubber
ITEM NO. : HS-M16
Other size
Operating Temperature: -40℃-100℃
Color: Black White
Package:100pcs or Special request Packing available
Brand: WAHSURE
Type: Metric Thread Cable Gland, M Type, Nylon Cable Gland, Metric Thread Cable Gland, M Type, Nylon Cable Gland,Tight ring from rubber
ITEM NO. : HS-M16
| Operating Temp. | ℃ | -40~100 |
| ℉ | -40~212 | |
| L1 | mm | 8 |
| Inch | 0.31 | |
| L | mm | 27 |
| Inch | 1.06 | |
| L2 | mm | 16 |
| Inch | 0.63 | |
| Spanne Size | mm | 22 |
| Inch | 0.87 | |
| Cable Range | mm | 5-10 |
Other size
| ITEM NO | L1 | Cable Range | L | Spanne Size | L2 |
| MM | MM | MM | MM | MM | |
| HS-M12 | 8 | 3-6.5 | 22 | 16 | 12 |
| HS-M14 | 8 | 4-8 | 26 | 19 | 14 |
| HS-M16 | 8 | 5-10 | 27 | 22 | 16 |
| HS-M18 | 8 | 5-10 | 27 | 22 | 18 |
| HS-M20 | 9 | 6-12 | 28 | 24 | 20 |
| HS-M22 | 10 | 10-14 | 30 | 27 | 22 |
| HS-M24 | 10 | 12-15 | 30 | 27 | 24 |
| HS-M25 | 10 | 13-18 | 35 | 33 | 25 |
| HS-M27 | 10 | 13-18 | 35 | 33 | 27 |
| HS-M30 | 11 | 12-21 | 34 | 35/36 | 30 |
| HS-M32 | 11 | 12-21 | 34 | 36/37 | 32 |
| HS-M36 | 12 | 18-25 | 40 | 41/42 | 36 |
| HS-M40 | 14 | 22-32 | 48 | 52/53 | 40 |
| HS-M50 | 14 | 32-38 | 49 | 60/61 | 50 |
| HS-M63 | 14 | 37-44 | 50 | 67 | 63 |
